High leg transformer

High leg delta, also known as wild-leg, stinger leg, bastard leg or high leg is a type of electrical service connection for three phase electric power installations. It is used when both single and three phase power is desired to be supplied from a three phase transformer.

What phase is the high leg?

The high-leg or phase with the higher voltage as measured to neutral has traditionally been designated “Phase B”. A change to the 2008 NEC now allows the high leg of a four-wire three-phase delta service to be labeled as the “C” phase instead of the “B” phase.

What voltage is the high leg in a delta transformer?

We are now ready to calculate the voltage across the high leg of the 4 wire delta transformer secondary with one center-tapped winding. The high leg voltage magnitude is approximately 208 volts with an angle of negative 30 degrees when a reference of zero degrees for the A Phase voltage (VAB) is used.

Does a delta transformer have a high leg?

A high leg delta connection is a configuration in which one of the windings in a delta connected secondary of a transformer is centre-tapped and grounded. It is also known as red leg connection or wild leg connection or orange leg connection.

Does all 3-phase have A high leg?

Other types of three-phase supplies are wye connections, ungrounded delta connections, or corner-grounded delta ("ghost" leg configuration) connections. These connections do not supply split single-phase power, and do not have a high leg.

What voltage is A high leg?

The midpoint of one phase winding is grounded to provide 120 Volts between phase A and neutral, and 120 Volts between phase C and neutral. The voltage is 208 Volts between phase B and neutral. This is referred to as the high leg.

Is 240V Wye or Delta?

In the US, 240V Power is provided to small buildings with large loads as 240V 3 Phase Open Delta. It's like 120 / 240V but also provides 240V 3 Phase for large loads (Machinery, etc.). It's often called “Wild Leg” of “High Leg” Delta because one leg (Phase B) is different.

Does 3-phase 480V have A neutral?

480V 3 Phase Delta is a 3 Wire power configuration and does not include a neutral wire.

Is 480 volts Delta or Wye?

The "480 Y" indicates the transformer is wye-connected and has 480 volts between any two phases.

Which is better Wye or Delta?

The Wye connection joins together one end of each of the coils and applies the individual phases to the open ends. These two connections produce very different results when power is applied. An advantage of the Delta connection is higher reliability.

What voltage is one leg of 480?

The voltage between any one leg and ground will be 277 volts, and between any 2 hot wires will be 480 volts.

How do you measure high leg voltage?

To get all these values, you may use the following simple math calculations (Phase, Lines and Hot represents the same thing). Voltage between Phase and Neutral = 1/2 x 240V = 220V (1-Φ). Voltage between High leg and Neutral = 1/2 x 220V x √3 = 208V (1-Φ). Voltage between two Hot Phases = 120V x 2 = 240V (1-Φ).

Is 208 Wye or Delta?

Three Phase Four Wire Wye The most common commercial building electric service in North America is 120/208 volt wye, which is used to power 120 volt plug loads, lighting, and smaller HVAC systems. In larger facilities the voltage is 277/480 volt and used to power single phase 277 volt lighting and larger HVAC loads.

How do you know if power is Delta or Wye?

Delta systems have four wires total: three hot wires and one ground wire. Wye systems utilize a star configuration, with all three hot wires connected at a single neutral point. One neutral wire and one ground wire make for a total of five wires in 3-phase Wye systems.

What does X6 mean on a transformer?

X6 is the center tap of X1-X3. A floating secondary with no external load will have voltages from the three terminals to ground (probably meaning to the transformer case) of varying values that will depend upon the leakage capacitance and resistance to the transformer case.

Does 240v 3-phase have a high leg?

So 3 phase 240 volt has a high leg. 2 of the 3 legs measured to ground measure 120v. While the high leg to ground measures 240v to ground.

Can you run a 3-phase motor on 240v?

The single phase to 3 phase VFD is the best option for a 3 phase motor running on single phase power supply (1ph 220v, 230v, 240v), it will eliminate the inrush current during motor starting, make the motor run from zero speed to full speed smoothly, plus, the price is absolutely affordable.

How much voltage should each leg of 3-phase?

Each of the 3 lines will be carrying 120 volts.

Can 240 volts be single-phase?

240V can be single phase or 3-phase. 120V can be single phase or 3-phase, but it would be unusual for it to be 3-phase. Single phase simple means that the AC power is delivered by one pair of wires. This post will also answer other questions in this series.

What is the voltage on 3 phase?

A common supply voltage is 120V/208V 3 phase Wye configuration. 120 volts is measured from each phase to neutral (neutral is center-tapped) and 208 volts is measured phase to phase.
